Woven 316L Stainless Steel Mesh Roll (Mesh 100-500, W100 mm * L1 m) as Battery Current Collector, CBCCWSS316LMR
Use your own shipping account?
We support FedEx, UPS, and DHL third-party billing for institutional customers.
Place your order first, then email shipping@echemsupplies.com with your account details and order number. We'll generate the label using your account and refund your shipping charges, less a handling fee.
The mesh-type 316L stainless steel (SS316L) is a 3D structural substrate used primarily in high-power lithium-ion batteries and next-generation lithium-metal anodes. Unlike the "microporous" foil which is a solid sheet with holes drilled into it, the mesh is created by stretching and expanding a copper sheet to form a series of round openings. The 3D architecture of mesh offers several distinct advantages for high-performance cells:
(1) Higher Active Material Loading: The open "pockets" of the mesh allow you to pack more slurry into the electrode, increasing the overall energy density of the cell.
(2) Enhanced Electrolyte Penetration: In aqueous or flow systems, the mesh ensures the electrolyte can reach the center of the electrode, reducing "dead zones" and improving rate capability.
(3) Superior Mechanical Interlocking: Active materials (like sulfur or manganese oxide) physically lock into the mesh pores, which prevents the delamination that often happens with flat foils during cycling.
(4) Wider Electrochemical Window: SS316L remains stable at higher voltages (up to ~5V) without the pitting or dissolution common in aluminum current collectors.
| Part Number |
CBCCWSS316LMR (C-BCC-WSS316LMR) |
| Purity |
>99.98% |
| Dimension |
(1) Mesh 100, T 0.2um * W 100mm * L 1m (2) Mesh 200, T 0.15um * W 100mm * L 1m
(3) Mesh 300, T 0.09um * W 100mm * L 1m
(4) Mesh 400, T 0.06um * W 100mm * L 1m
(5) Mesh 500, T 0.05um * W 100mm * L 1m
Other dimensions can also be supplied upon request.
|
| Main Application Fields |
1. Aqueous Battery (eg: aqueous ZIB) |
