Platinum/Carbon (Pt/C, 60 wt%) Coated Electrode (0.5 mg/cm2) for Electrolyzer and Fuel Cell, CEFCCEPtC
Use your own shipping account?
We support FedEx, UPS, and DHL third-party billing for institutional customers.
Place your order first, then email shipping@echemsupplies.com with your account details and order number. We'll generate the label using your account and refund your shipping charges, less a handling fee.
Platinum on Carbon (Pt/C) is the industry-standard catalyst for handling the hydrogen-side reactions in both fuel cells and electrolyzers. The role of the Pt/C electrode changes dramatically depending on whether it is "pushing" electrons (electrolysis) or "pulling" them (fuel cell).
In an PEM electrolyzer, (1) Hydrogen Evolution (HER): Pt/Vulcan is the standard cathode for water splitting. (2) Cathode Environment: Since the cathode operates at low (reducing) potentials, the Vulcan XC-72 carbon is extremely stable and can last for tens of thousands of hours without degrading
In PEM fuel cell, (1) Oxygen Reduction (ORR): Most commercial cathode catalysts are 20% to 60% Pt/Vulcan. The carbon must provide a stable path for electrons to reach the oxygen molecules. (2) Durability: At the cathode, the high voltage and moisture can cause the Vulcan XC-72 to slowly corrode (carbon oxidation). Researchers often use "Graphitized" Vulcan (heat-treated at >1000°C) to make the carbon more resistant to this decay.
| Part Number |
CEFCCEPtC |
| Electrode Active material |
60 wt% platinum nanoparticles on Vulcan XC-72 carbon black |
| Carbon Cloth Substrate |
Thickness: 410 um Density: 200 g/m2 Air Permeability: < 55 s Fiber length: 35 mm Electrical Resistivity (through plane) < 13 mΩcm² Microporous layer is located at the catalyst side |
| Carbon Paper Substrate |
Thickness: 215 um Density: 70 g/m2 Water Contact Angle (MPL side): > 130° Substrate PTFE Treatment: 5 wt% Microporous layer is located at the catalyst side |
| Titanium Felt Substrate |
Thickness: 250 um Porosity: 60-70% Fiber length: 70 mm Fiber diameter: 25-50 um |
| Loading Amount |
0.5 mg/cm2 |
| Electrode Dimension |
L 10cm * W 10cm (Other sizes, such as 20cm*20cm, 30cm * 30cm, 40cm*40cm can be supplied upon request) |
| Package Size | 1 pcs/pack |
Notes: Please try to store the Pt/C coated electrodes in a dry place.
References:
- S. J. Yen, et al. The improvement of catalytic efficiency by optimizing Pt on carbon cloth as a cathode of a microbial fuel cell, Electrochimica Acta., 2013, 108, 241-247.
-
Q. Wang, et al. Carbon fiber paper supported nano-Pt electrode with high electrocatalytic activity for concentrated nitric acid reduction, J. Electroanalytical Chem., 2017, 794, 43-48.
