Cobalt-Free Single-Crystal Lithium-Rich Manganese-Based Oxides Li1.5Ni0.25Mn0.75O2.5 (LRMOs) Powder for High-Voltage (~5V) Li-Ion Battery Cathode, 50-200 g/bottle, CHVLIBCSCLRMO15
Use your own shipping account?
We support FedEx, UPS, and DHL third-party billing for institutional customers.
Place your order first, then email shipping@echemsupplies.com with your account details and order number. We'll generate the label using your account and refund your shipping charges, less a handling fee.
Add-Ons
Cobalt-Free Single-Crystal Lithium-Rich Manganese-Based Oxide (Li1.5Ni0.25Mn0.75O2.5, LRMO) is an advanced, high-capacity cathode material designed for ultra-high-energy-density lithium-ion batteries operating at voltages approaching ~ 4.8 V vs. Li/Li+.
Its main features are: (1) Dual-Mechanism Capacity: Combines traditional transition metal redox (Ni^{2+/4+}) with reversible anionic oxygen redox activated during the initial high-voltage charge plateau above 4.5 V, yielding an exceptionally high reversible specific capacity exceeding 250-280 mAh/g. (2) Single-Crystal Morphology Advantage: By eliminating internal grain boundaries inherent in polycrystalline lithium-rich oxides, the sub-micron single-crystal morphology drastically suppresses intergranular microcracking induced by anisotropic lattice volume changes during deep oxygen-redox activation and high-voltage cycling. (3) Cobalt-Free Sustainability: Relies exclusively on earth-abundant nickel and manganese, significantly lowering material costs and eliminating geopolitical supply-chain vulnerabilities associated with cobalt. (4) Vulnerability: Suffers from gradual voltage decay (voltage fade) over extended cycling due to localized transition-metal layer migration and structural rearrangement from layered to spinel-like phases, requiring precise surface passivation.
| Part Number |
CHVLIBCSCLRMO15 (C-HVLIB-C-SCLRMO15) |
| Chemical Composition |
Li: 9.11 wt%, Ni+Mn = 51.97% humidity level<0.021 wt%, Impurities: Zn, Cu<0.0001 wt%, Ca<0.0032 wt%, Na<0.0064 wt%, Mg<0.0028 wt% |
| Particle Size Distribution |
D10 = 3.37 um; D50 = 6.29 um; D90 = 10.92 um |
| Tap Density | 2.25 g/cm3 |
| Specific Area | 1.96 m2/g |
| First Discharging Capacity |
~233 mAh/g (coin cell, 0.1 C, 2.3-4.55 V) |
| First Columbic Efficiency |
88.27% |
| Package Grade |
50 g, 100 g, and 200 g |
Notes: (1) Please store the Li1.5Ni0.25Mn0.75O2.5 (LRMOs) in a dry area (glovebox is preferred); (2) The battery powder is highly recommended to be dried at 80-100°C in a vacuum oven for 6-12 h before use.
References:
- L. Yan, et al., Preparation of Single-Crystal Li-Rich Mn-Based Layered Oxides with Excellent Electrochemical Performance via Simple Stepwise High-Temperature Sintering, ACS Appl. Mater. Interfaces (2024) 16 (44): 60166–60179.
- T. Yang, et al., Toward next-generation cathodes for lithium-ion batteries: progress and prospects of single-crystal lithium-rich manganese-based oxides, EES Batteries (2026) 2 (2): 377–404.
