The Lithium Titanate (Li4Ti5O12) coated on aluminum foil electrode (disc, sheet, roll) can be used as lithium-ion battery anode. The round disc shape with single-side coating is suitable for coin cell testing, while the rectangle sheet shape with single- or double-side coating is designed for single-layer or multiple-layer pouch cell testing. The roll shape with double-side coating is designed for cylindrical cell electrodes after slitting.
| Part Number | CLIBAELTO (C-LIB-AE-LTO) |
| Current collector | 15 um aluminum foil |
| Coating Material | Lithium Titanate (Li4Ti5O12) powder with surface carbon |
| Coating Slurry Recipe | LTO : PVDF: Super P = 95% : 2% : 3% |
| Electrode Dimension |
Round disc shape: D = 16 mm Rectangle sheet shape: Substrate (L240mm*W200mm); Coating: (L240 mm*175 mm, empty width of 12.5 mm at each side for tab welding) Roll shape: 10 m length |
| Package Size |
Round disk D10-SZKJ16 mm (50 pcs/pack) Rectangle sheet with SS & DS coating (5 pcs/pack) Roll shape: 1 roll |
| Loading Mass Density | 11.0 mg/cm2 (single side); 22.0 mg/cm2 (double side) |
| Compaction Density | 1.6 g/cm3 (single side); 1.8 g/cm3 (double side) |
| First Discharging Capacity | ~162 mAh/g |
| First Columbic Efficiency | 91.0% (Recommended Electrolyte: 1M LiPF6 in ECEC:DMC:EMC=1:1:1 with 1.0%VC, 1-3 cycles of formation should be done before real testing) |
Notes: (1) Please store the LTO electrodes in a dry area (glovebox is preferred); (2) The battery electrodes are highly recommended to be dried at 80-100°C in a vacuum oven for 6-12 h before use.
References:
- G. N. Zhu, et al. A Comprehensive Study of Effects of Carbon Coating on Li4Ti5O12 Anode Material for Lithium-Ion Batteries, J. Electrochem. Soc., 2011, 158, A102.
-
X. Guo, et al. Carbon coating of Li4Ti5O12 using amphiphilic carbonaceous material for improvement of lithium-ion battery performance, J. Power Sources, 2012, 214, 107-112.
