LiNi0.90Co0.05Mn0.05O2 (NCM9055, Polycrystalline) Powder with Lithium Niobate (LiNbO3) Coating for Li-Ion Battery Cathode, 100-500 g/bottle, CLIBCNCM9055LNO
Use your own shipping account?
We support FedEx, UPS, and DHL third-party billing for institutional customers.
Place your order first, then email shipping@echemsupplies.com with your account details and order number. We'll generate the label using your account and refund your shipping charges, less a handling fee.
Add-Ons
LiNi0.90Co0.05Mn0.05O2 (NCM9055, Polycrystalline) with Lithium Niobate (LiNbO3) Coating represents a state-of-the-art cathode architecture engineered for high-energy-density lithium-ion and solid-state batteries. By combining an ultra-high-nickel NCM9055 core with a fast ion-conducting protective surface layer, this material overcomes the severe degradation challenges typically associated with deep delithiation and high-voltage operation.
The main features of the LNO-coated NCM9055 powder are: (1) Polycrystalline Secondary Morphology: Unlike single-crystal variants, polycrystalline NCM9055 consists of spherical secondary agglomerates formed by radially oriented primary nanograins. This structure provides high tap density and extensive point-to-point contact areas for solid electrolytes (such as Li6PS5Cl) or liquid electrolyte wetting. (2) Ultra-High Nickel Content (90% Ni): Delivers exceptional specific discharge capacities routinely exceeding 210 to 220 mAh/g, maximizing gravimetric and volumetric energy density. (3) LiNbO3 Surface Nanolayer: The conformal lithium niobate coating acts as a fast Li+ conductor, effectively suppressing space-charge layer (SCL) resistance and preventing parasitic oxidation at aggressive high operating voltages. (4) Mechanical Considerations: While the polycrystalline architecture offers rapid ion transport kinetics, it requires controlled upper cutoff voltages and uniform stack pressure to manage intergranular micro-cracking caused by anisotropic lattice contraction during deep delithiation.
| Part Number |
CLIBCNCM9055LNO (C-LIB-NCM9055-LNO) |
| Chemical Composition |
Li: 7.15 wt% Ni: 90.4 mol%, Co: 6.01 mol%, Mn: 3.95 mol% |
| Impurity Content |
Fe: <0.0003 wt%; Na: <0.0035 wt%; Ca: <0.0054 wt% |
| Particle Size Distribution |
D10 = 6.17 um; D50 =10.22 um; D90 = 17.69 um |
| Tap Density | 2.61 g/cm3 |
| Specific Area | 0.68 m2/g |
| Water Level | <230 ppm |
| First Discharging Capacity |
~221.1 mAh/g (0.1 C, 3.0-4.3 V) |
| First Columbic Efficiency |
90.33% |
| Package Grade |
100 g, 200 g, and 500 g/bottle |
Notes: (1) Please store the NCM9055@LNO powder in a dry area (glovebox is preferred); (2) The battery powder is highly recommended to be dried at 80-100°C in a vacuum oven for 6-12 h before use.
