Hydrophilic Surfactant Coated PP (Polypropylene, Celgard 3501) Disk or Roll as Aqueous Battery Separator, CABSHSPPC3501
Use your own shipping account?
We support FedEx, UPS, and DHL third-party billing for institutional customers.
Place your order first, then email shipping@echemsupplies.com with your account details and order number. We'll generate the label using your account and refund your shipping charges, less a handling fee.
Celgard 3501 separator is a 25µm thick, monolayer microporous polypropylene (PP) membrane specifically engineered for aqueous electrolyte battery systems. Its most critical feature is a surfactant coating, which allows for rapid wetting in water-based electrolytes that would otherwise be repelled by standard hydrophobic plastic films. The key features of the Celgard 3501 separator is: (1) Rapid wetting; (2) Low impedance; (3) Dimensional stability; (4) Chemical resilience. Its mainly application is aqueous battery systems: specifically used in Nickel-Zinc (NiZn), Nickel-Cadmium (NiCd), and Zinc-Air batteries.
| Part Number |
CABSHSPPC3501 (C-ABS-HSPP-C3501) |
| Material |
PP (Polypropylene) with hydrophilic surfactant coating |
| Thickness |
T=25 um |
| Dimension |
(1) Round Disk: D=16 mm (100 pcs/pack) (2) Round Disk: D=19 mm (100 pcs/pack) (3) Roll: W55 mm * L3 m (1 roll/pack) (4) Roll: W60 mm * L5 m (1 roll/pack) (5) Roll: W80 mm * L3 m (1 roll/pack) (6) Roll: W80 mm * L5 m (1 roll/pack) (7) Roll: W100 mm * L5 m (1 roll/pack) (Roll with other width and length can be supplied upon request) |
| Gurley Value |
200 |
| Porosity |
55% |
| Puncture Strength |
325 gf |
| Wettability (max- internal) |
30 seconds |
References:
