Temperature-Sensitive Carbon Coated Aluminum Foil Sheet or Roll as Dry Electrode Battery Cathode Current Collector, CDEBCCCTSCAF
Use your own shipping account?
We support FedEx, UPS, and DHL third-party billing for institutional customers.
Place your order first, then email shipping@echemsupplies.com with your account details and order number. We'll generate the label using your account and refund your shipping charges, less a handling fee.
Carbon-coated aluminum foil is a high-performance evolution of the standard cathode current collector. It consists of a high-purity aluminum foil (typically 12 um to 25 um thick) that is coated on one or both sides with a sub-micron layer (0.5 um to 2 um) of conductive carbon—typically a mix of carbon black, graphite, or graphene. The carbon-coated current collector is the "bridge" that makes this transition possible by ensuring that the dry-processed film doesn't delaminate or lose electrical contact during the thousands of expansion/contraction cycles a car battery undergoes. The temperature-sensitive properties are suitable for dry electrode fabrication under mild temperature range (~60-80 °C).
| Part Number |
CDEBCCCTSCAF (C-DEBCCC-TSCAF) |
| Dimension |
(1) Double-Side Carbon Coating Sheet: T (1+12+1)um * W (15+150+15)mm * L 200 mm, 5 pcs/pack {Al foil and carbon width: 180 mm and 150 mm, the empty area for each side is 15 mm. Al foil and coating thickness is 12 um and 1 um (each side} (2) Double-Side Carbon Coating Roll: T (1+12+1)um * W (15+150+15)mm, 1.0 kg/roll {Al foil and carbon width: 180 mm and 150 mm, the empty area for each side is 15 mm. Al foil and coating thickness is 12 um and 1 um (each side} |
References:
- I. Doberdò, et al.,Enabling aqueous binders for lithium battery cathodes – Carbon coating of aluminum current collector, J. Power Sources, 2014, 248, 1000-1006.
-
T. Li, et al., Carbon-coated Aluminum Foil as Current Collector for Improving the Performance of Lithium Sulfur Batteries, I. J. Electrochem., Soc., 2017, 12, 3099-3108.
