LiPF6/PVDF-HFP-Based Gel Polymer Electrolyte for Li-Ion Battery, 50-200 g/bottle, CGPELPFPVDFHFP
Use your own shipping account?
We support FedEx, UPS, and DHL third-party billing for institutional customers.
Place your order first, then email shipping@echemsupplies.com with your account details and order number. We'll generate the label using your account and refund your shipping charges, less a handling fee.
Poly(vinylidene fluoride-co-hexafluoropropylene) (PVDF-HFP)-based Gel Polymer Electrolyte (GPE) plasticized with a LiPF6-carbonate liquid electrolyte represents one of the most mechanically robust and electrochemically stable gel systems for advanced lithium-ion batteries
The main features of the LiPF6/PVDF-HFP-Based gel polymer electrolyte are: (1) Dual-Phase Morphology: The semi-crystalline structure features crystalline PVDF blocks providing structural integrity and mechanical strength, while amorphous HFP domains swell extensively with liquid carbonate electrolytes, trapping them within a three-dimensional polymer network. (2) High Ionic Conductivity: Swelling with 1.0 M LiPF6 liquid electrolyte yields high room-temperature ionic conductivity (>10^{-3} S/cm comparable to liquid electrolytes while eliminating free-flowing liquid leakage risks. (3) Interfacial Compatibility: Exhibits excellent wettability and stable solid electrolyte interphase (SEI) formation when paired with both high-voltage cathodes and graphite or silicon-carbon anodes.
| Part Number |
CGPELPFPVDFHFP (C-GPE-LPFPVDFHFP) |
| Appearance |
Transparent gel |
| Gel Composition |
1.0 M LiPF6 in EC:DMC=1:1 vol% + 5% FEC Host polymer matrix: 20 wt% PVDF-HFP Plasticizer: 5 wt% Dibutyl phthalate (DBP) Solvent: Anhydrous acetone |
| Viscosity |
~1000-1500 mPa*s |
| Solid Content |
~20% |
| Ionic Conductivity |
~1.0-4.4 x10-3 S/cm at RT |
| Electrochemical Window |
4.5-4.8 V |
| Package Size | 50 g, 100 g, and 200 g/bottle |
Notes: Please try to store the LiPF6/PVDF-HFP gel polymer electrolyte in a dry place.
References:
- H. X. Yang, et al. Multiscale Structural Gel Polymer Electrolytes with Fast Li+ Transport for Long-Life Li Metal Batteries, Adv. Funct. Mater., 2023, 33, 2209837
- G. Chen, et al. A Flexible Dual-Ion Battery Based on PVDF-HFP-Modified Gel Polymer Electrolyte with Excellent Cycling Performance and Superior Rate Capability, Adv. Energy Mater., 2018, 8, 1801219.
