Aluminum Laminated Film Sheets (L 115-210 mm, W 100-120 mm, T= 113 um) as Pouch Cell Cases, 25 pcs/pack, CPCCALFS
Use your own shipping account?
We support FedEx, UPS, and DHL third-party billing for institutional customers.
Place your order first, then email shipping@echemsupplies.com with your account details and order number. We'll generate the label using your account and refund your shipping charges, less a handling fee.
The aluminum laminated film is the cases for pouch cell application. It is consisting of nylon, glue, Al, and PP layers that is resistant to the high temperature and chemical corrosion. The sheet pieces are good for researcher to directly used for case formation without any slitting.
| Part Number |
CPCCALFS (C-PCC-ALFS) |
| Laminated Film Structure |
T113 um (from outside to inside for laminated film) Polyamide (PA): 25 um, Dry Laminant (DL): 3 um Aluminum (AL): 40 um Polypropylene (PP): 45 um  |
| Pouch Case Size |
(1) L115 mm * W100 mm * T113 um
(2) L160 mm * W100 mm * T113 um
(3) L200 mm * W120 mm * T113 um
(4) L210 mm * W100 mm * T113 um
(5) L240 mm * W200 mm * T113 um
(6) L400 mm * W300 mm * T113 um
(7) L500 mm * W400 mm * T113 um
Package grade: 25 pcs/pack
|
| Use Notes |
Please make sure the white shiny side of PP layer is folded inside to hot laminated with tab adhesive (black side is used as outside of pouch cell). |
