Lithium-Indium (Li-In) Alloy Coated Copper Foil as Solid-State Battery Anode, 1 m/pack, CSSBALIACF
Use your own shipping account?
We support FedEx, UPS, and DHL third-party billing for institutional customers.
Place your order first, then email shipping@echemsupplies.com with your account details and order number. We'll generate the label using your account and refund your shipping charges, less a handling fee.
Using a pre-fabricated Lithium-Indium (Li-In) alloy coated copper foil is an excellent choice for roll-to-roll scaling and uniform pouch cell assembly. It completely bypasses the tedious, inconsistent process of manually laminating pure lithium and indium foils inside a glove box.
The structural layers of a pre-coated foil are stacked to optimize electronic contact and electrochemical boundaries: (1) Protective 0.62 V Barrier: When a pure lithium metal anode meets a sulfide solid electrolyte (Li6PS5Cl, LGPS), the extremely low chemical potential (~ 0 V) reduces the electrolyte, generating resistive decomposition products (Li2S, Li3P). The Li-In coating shifts the operational threshold up to ~ 0.62 V vs. Li/Li+. This thermodynamically protects the solid electrolyte separator from reduction. (2) Intimate Electronic Contact: Depositing the alloy layer directly onto a treated copper foil ensures a near-zero interfacial resistance on the backside of the anode, preventing local current hotspots.
| Part Number |
CSSBALIACF (C-SSBA-LIACF) |
| Composition |
Li : In= 1:1 (atomic ratio) |
| Foil Sizes |
(1) 20um*60mm Li-In + 8um*80mm Cu (Single Side, Central), L 1m (2) 20um*60mm Li-In + 8um*80mm Cu + 20um*60mm Li-In (Double Side, Central), L 1m (3) 50um*60mm Li-In + 8um*80mm Cu (Single Side, Central), L 1m (4) 50um*60mm Li-In + 8um*80mm Cu + 50um*60mm Li-In (Double Side, Central), L 1m Other customized sizes (eg: single/double coating, coating width and thickness, and current collector thickness) can be supplied upon request. |
| Sample Package |
The lithium-indium coated copper foil roll is sealed in an aluminum bag filled with Ar gas. |
| Attention |
The lithium-indium coated copper foil roll must be opened and operated inside a glove box with Argon Gas and moisture less than 1%RH (0.1 ppm is better). |
References:
- J. Aspinall, et al. Effect of Microstructure on the Cycling Behavior of Li–In Alloy Anodes for Solid-State Batteries, ACS Energy Lett. 2024, 9, 2, 578–585.
- P. Molaiyan, et al. Optimizing Current Collector Interfaces for Efficient “Anode-Free” Lithium Metal Batteries, Adv. Funct. Mater., 2024, 34, 2311301
